28mm OD Standard Gearbox BLDC Planetary Gear Motor 4 Poles
Datos del producto:
| Lugar de origen: | Dongguan China |
| Nombre de la marca: | UCHI |
| Certificación: | Completed |
| Número de modelo: | 30JM30K/B2847 |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1000pcs |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Estándar |
| Tiempo de entrega: | 5-7 días |
| Condiciones de pago: | T/t, unión occidental |
| Capacidad de la fuente: | 5000 piezas de piezas |
|
Información detallada |
|||
| Número de polos: | 4 | Rango operativo: | 9V ~ 16V / 9C ~ 26V |
|---|---|---|---|
| Corriente nominal mA: | 130/70 | Certificado: | 3C |
| Velocidad sin carga r/min: | 7300 | Corriente de no carga mA: | 270/180 |
| Velocidad nominal r/min: | 5500/6000 | Poder clasificado W: | 7.3/8.0 |
| Resaltar: | 4 Poles BLDC Planetary Gear Motor,Planetary Gearbox BLDC Planetary Gear Motor |
||
Descripción de producto
30JM30K/B2847 28mm OD Standard Gearbox BLDC Planetary Gear Motor 4 Poles
Features
1.Brushless motor built-in driver, with a positive inversion, speed control, brake (brake) function.
2.28mm OD Planetary Gearbox,
Permissible Load Range: 0.3N.m~3.0N.m
Dimensions
Brushless Motor Technical Data
| TYPE | Number of poles |
Number of phase |
Operating Range |
Rated voltage VDC |
No- load speed r/min |
No- load current mA |
Rated torque g.cm |
Rated speed r/min |
Rated current mA |
Rated power W |
|||||||||||||
| B2847-1273 | 4 | 3 | 9V~ 16V | 12 | 7300 | 270 | 130 | 5500 | 130 | 7.3 | |||||||||||||
| B2847-2473 | 4 | 3 | 9V~26V | 24 | 7300 | 180 | 130 | 6000 | 70 | 8.0 | |||||||||||||
Brushless Gear Motor Technical Data
1.B2847-1273 BLDC Motor
2.B2847-2473 BLDC Motor
Wire Diagram
PIN 1# (Blue) Brake control
PIN 2# (Orange) PWM speed regulation: Input a 20~30kHz PWM signal, and adjust the motor speed by adjusting the duty cycle.
PIN 3# (Black) Negative pole of power supply
PIN 4# (White) Forward and Reverse Rotation: Suspended steering is CCW, short circuited to ground steering is CW.
PIN 5# (Green) Feedback n=60 * F/P, where F is the feedback frequency and P is 4 pairs of motor pole pairs.
PIN 6# (Red) Positive pole of power supply
Connection line length 200mm
